Roll to Roll Strip Stamping Machine – 12" Hot Stamping Machine

It is a hot foil stamping machine in which the stamping element is a heated roll rather than a flat plate. The strip or tape runs from an unwinding unit, passes between the heater roll and its counter roll with foil in between, and is rewound. Because the roll turns continuously with the web, the foil is applied along the strip without stopping and starting.

The machine is sized for 12" work. Web tension is managed by electronic web control, the stamping temperature is set on a temperature controller unit, and a meter counter records the length run. The unwinding side carries a two roll disc attachment, and the up and down rewinding system winds the finished strip. The machine occupies a footprint of about 5.6 ft by 4.8 ft and stands 3.6 ft high.

Heater Roll for Continuous Stamping

The heated roll stamps foil onto the strip as it turns, producing an unbroken foil design along the length of the tape. Repeating patterns and continuous lines come out without joins.

12" Working Size

The machine is built for 12" width, covering single wide strips or several narrow tapes side by side in one pass.

Electronic Web Control

Strips and tapes are light and stretch easily. Electronic web control keeps tension steady from unwind to rewind so the foil is applied evenly and the finished roll winds tight and straight.

Temperature Controller Unit

Foil adhesion depends on the right heat for the foil and the material. The temperature controller unit lets the operator set and hold the stamping temperature for each job.

Meter Counter

A meter counter records the length of strip stamped, so orders are run to the correct quantity and production is easy to track.

Two Roll Disc Unwinding Attachment

The unwinding side is fitted with a two roll disc attachment, holding the strip roll steady as it feeds into the stamping section.

Up and Down Rewinding System

The finished strip is wound on an up and down rewinding system, which allows the operator to manage rewinding without stopping the machine between rolls.

Compact, Low Power

A 1 HP AC variable speed motor on three phase power drives the machine, and the footprint of about 5.6 ft by 4.8 ft fits a small finishing area.

The strip roll is mounted on the two roll disc unwinding attachment and the foil roll is loaded on its own spindle. The strip and the foil are threaded together between the heater roll and its counter roll, and the strip continues to the up and down rewinding system. The operator sets the stamping temperature on the temperature controller unit and the speed on the AC variable speed drive.

When the machine runs, the heated roll presses the foil against the moving strip, and the foil's carrier is taken away leaving the metallic layer bonded to the tape in the pattern of the roll. Electronic web control holds the strip tension steady across the process, the meter counter tallies the length, and the finished strip winds on the rewinding system. Job changes involve swapping the foil and, for a new pattern, the stamping roll.

• Gift and decorative ribbons – continuous foil patterns and borders on ribbon rolls.
• Garment and textile tapes – metallic lines and repeat designs on tapes and trims.
• Packaging strips – foil bands on tear strips and packaging tapes.
• Narrow label webs – continuous foil edges or backgrounds on narrow label strips before printing or cutting.
• Stationery and craft strips – foiled borders and bands on paper and card strips.

The machine foils strips and tapes up to 12" wide in materials commonly used for ribbons, tapes and narrow webs, including paper, fabric tape and film strips, with hot stamping foils suited to each. Foil adhesion varies with the material, so share your strip and foil samples with RK so the heater roll temperature and web tension are set correctly.

• Double Head Stamping Machine RK-HSD 3030high speed flatbed stamping and label die cutting with servo cross foil saving.
• Stamping & Embossing Machine RK 2530-Eheavy duty stamping, embossing and die cutting with auto sheet cutting.

RK Label Printing Machinery Pvt. Ltd. has manufactured label printing and converting machinery in Ahmedabad, Gujarat since 1995, operates three manufacturing units and supplies customers in 23+ countries. The roll to roll strip stamping machine sits at the compact end of RK's foil stamping range, alongside the flatbed RK-HSD 3030 and the heavy duty RK 2530-E, so a customer can choose continuous roll stamping or stroke-by-stroke flatbed stamping depending on the work. Each machine is set up against the customer's strip widths and foil designs rather than sold as a fixed model.

• Continuous or spot foil: a repeating or continuous foil design along a strip suits the roll to roll machine; a single image per label suits a flatbed stamping head.
• Strip width: all strips must fit within the 12" working size, singly or side by side.
• Material: ribbon, tape, paper or film; each needs its own temperature setting on the controller.
• Roll handling: the two roll disc unwinding attachment and up and down rewinding suit continuous roll production.
• Power and space: 1 HP three phase motor and a footprint of about 5.6 ft by 4.8 ft.

The price of the Roll to Roll Strip Stamping Machine depends on the stamping roll, unwinding and rewinding arrangement and options chosen. Prices are quoted ex-works Ahmedabad with GST at 18% applicable; engineer travel and stay for installation and training at your site are borne by the customer. Share your strip widths, materials and foil designs with RK and the engineering team will recommend a configuration and quote against it.
